Configuring the UDC Module’s Registers 3-35
Power Device Status Register (Continued) 204/1204
Phase W-Lower IOC A Bit 5
The Phase W-Lower A status bit is set if an
IOC or DSAT fault occurs in Power Module
A’s phase W, lower power device. Hex Value: 0020H
Sug. Var. Name: W_LOA@
Access: Read only
UDC Error Code: N/A
LED: N/A
Intelligent Power Module A Bit 6
The Intelligent Power Module A bit is set to
indicate that a DSAT (shoot-through) fault
has occurred in Power Module A. Bits 0 - 5
should be checked to identify the device in
which the fault occurred. Hex Value: 0040H
Sug. Var. Name: IPMA@
Access: Read only
UDC Error Code: N/A
LED: N/A
GDI Fault A Bit 7
The GDI Fault A bit is set if a problem is
detected with the power supply of Power
Module A’s Gate Driver Interface module. Hex Value: 0080H
Sug. Var. Name: GDIA@
Access: Read only
UDC Error Code: N/A
LED: N/A
Charge Fault Bit 8
The Charge Fault A bit is set if a charge bus
time-out fault occurs in Power Module A.
(refer also to register 202/1202, bit 6). Hex Value: 0100H
Sug. Var. Name: CHGA@
Access: Read only
UDC Error Code: N/A
LED: N/A
Phase U Loss Bit 9
The Phase U Loss bit is set if AC line phase
U is lost. Hex Value: 0200H
Sug. Var. Name: U_PL@
Access: Read only
UDC Error Code: N/A
LED: N/A
Phase V Loss Bit 10
The Phase V Loss bit is set if AC line phase
V is lost. Hex Value: 0400H
Sug. Var. Name: V_PL@
Access: Read only
UDC Error Code: N/A
LED: N/A
