SECTION 6
REPLACEMENT PARTS
6.0 General - Users should consider maintaining a
stock along with part numbers and quantities actually
used in ofspare parts. Table 6.A lists the more common
parts the controller.
Table 6.A - Replacement Modules
Part Description
Quantity Per
Controller Model Number Part Number
Regulator Module
Digital Driver Module
Field Loss PC
Current Transformer (1CT, 3CT)
3 to 10 HP 230 VAC
3 to 20 HP 460 VAC
15 to 20 HP 230 VAC
25 to 40 HP 460VAC
Field Current Transformer
Power Cubes
3 - 20 HP 230 VAC
3 - 40 HP 460 VAC
M Contactor (Optional)
3 - 10 HP 230 VAC
15 - 20 HP 230 VAC
3 - 40 HP 460 VAC
Pilot Relay PC Card
10HP - 20 HP 230 VAC
3 - 40 HP 460 VAC
MOV Surge Suppressor
3 - 20 HP 230 VAC
3 - 40 HP 460 VAC
DV/DT PC Card
3 - 20 HP 230 VAC
3 - 40 HP 460 VAC
DV/DT Resistor Assembly
3 - 40 HP 460 VAC
Line Fuses 4FU, 5FU, 6FU
3 - 10 HP 230 VAC
3 - 20 HP 460 VAC
15 - 20 HP 230 VAC
25 - 40 HP 460 VAC
115 VAC Control Fuse, 3FU
1
1
1
2
2
2
2
1
3
3
1
1
1
1
1
3
3
1
1
1
3
3
3
3
1
14C650
14C651
14C652
14C653
14C653
14C654
14C654
14C655
14C266
14C267
14C268
14C268
14C212
14C270
14C271
14C260
14C261
14C214
14C214
14C215
-
-
-
-
14C670
0Ć57160
0Ć57170
0Ć54340Ć3
64670Ć22R
64670Ć22R
64670Ć23R
64670Ć23R
64670Ć24R
701819Ć19AC
701819Ć19AW
69326Ć30R
78090Ć51R
78090Ć51R
0Ć54335Ć1
0Ć54335Ć1
411026Ć6R
411026Ć9R
0Ć55310
0Ć55320
78089Ć6R
64676Ć12BX
64676Ć12BX
64676Ć12CC
64676Ć12CC
64676Ć23V
