C-4
ControlNet Communications Module
C.2 Register Object
Class Code
Instances
Class Attributes
Hexadecimal
Decimal
0x07
7
Instance
Description
1
All I/O data being read from the DPI device (read-only)
2
All I/O data written to the DPI device (read/write)
3
Logic Status and Feedback data (read-only)
4
Logic Command and Reference data (read/write)
5
Datalink A (input data from device to scanner) (read only)
6
Datalink A (output data from scanner to device) (read/write)
7
Datalink B (input data from device to scanner) (read only)
8
Datalink B (output data from scanner to device) (read/write)
9
Datalink C (input data from device to scanner) (read only)
10
Datalink C (output data from scanner to device) (read/write)
11
Datalink D (input data from device to scanner) (read only)
12
Datalink D (output data from scanner to device) (read/write)
13
Logic Status and Feedback Data (read-only)
14
Mask
1
(read/write)
1
The mask command word is set to the value of the first word of the data
where there are ones in the second word of the data. Command = (word
1 and not word 2) or (word 1 and word 2). This only controls specified bits
in the Logic Command data to the DPI product and does not change the
Reference value.
Attribute
ID
Access
Rule
Name
Data Type
Description
100
Set
Control Timeout UINT
Control timeout in
seconds
