Page 100

8-6
ControlNet Communications Module
8.2
Module Diagnostic Items
Table 8.5 lists diagnostic items that can be accessed using
VS Utilities software or the LCD OIM.
Table 8.5 – Module Diagnostic Items
No.
Event
Description
1
Common Logic
Cmd
The current value of the Common Logic
Command being transmitted to the host.
2
Prod Logic Cmd
The current value of the Product-Specific Logic
Command being transmitted to the host.
3
Reference
The current value of the Product-Specific
Reference being transmitted to the host.
4
Common Logic Sts The current value of the Common Logic Status
being received from the host.
5
Prod Logic Sts
The current value of the Product-Specific Status
being received from the host.
6
Feedback
The current value of the Product-Specific
Feedback being received from the host.
7
Datalink A1 In
The current value of Datalink A1 being
transmitted to the host. (Value of 0 if datalink is
not used).
8
Datalink A2 In
The current value of Datalink A2 being
transmitted to the host. (Value of 0 if datalink is
not used).
9
Datalink B1 In
The current value of Datalink B1 being
transmitted to the host. (Value of 0 if Datalink is
not used).
10
Datalink B2 In
The current value of Datalink B2 being
transmitted to the host. (Value of 0 if Datalink is
not used).
11
Datalink C1 In
The current value of Datalink C1 being
transmitted to the host. (Value of 0 if Datalink not
used).
12
Datalink C2 In
The current value of Datalink C2 being
transmitted to the host. (Value of 0 if Datalink is
not used).
13
Datalink D1 In
The current value of Datalink D1 being
transmitted to the host. (Value of 0 if Datalink is
not used).
14
Datalink D2 In
The current value of Datalink D2 being
transmitted to the host. (Value of 0 if Datalink is
not used).
15
Datalink A1 Out
The current value of Datalink A1 being received
from the host.
16
Datalink A2 Out
The current value of Datalink A2 being received
from the host.
