Rockwell Automation MPAI Heavy Duty Electric Cylinders User Manual
Page 33
MP-Series Heavy Duty Electric Cylinders 33
Rockwell Automation Publication MPAI-IN001E-EN-P - March 2012
Axis Properties Tab
Parameter
Cat. No.
Entry/Selection, with applicable distance unit settings
Metric Value mm/s
English Valuein/s
Dynamics
Maximum Speed
MPAI-x2076CM1xx
304
12.0
MPAI-x2150CM3xx
304
12.0
MPAI-x2300CM3xx
304
12.0
MPAI-x3076CM1xx
305
12.0
MPAI-x3076EM1xx
620
25.2
MPAI-x3076RM1xx
305
12.0
MPAI-x3076SM1xx
610
25.2
MPAI-x3150CM3xx
279
11.0
MPAI-x3150EM3xx
559
22.0
MPAI-x3150RM3xx
279
11.0
MPAI-x3150SM3xx
559
22.0
MPAI-x3300CM3xx
279
11.0
MPAI-x3300EM3xx
559
22.0
MPAI-x3300RM3xx
279
11.0
MPAI-x3300SM3xx
559
22.0
MPAI-x3450CM3xx
188
7.4
MPAI-x3450EM3xx
376
14.8
MPAI-x3450RM3xx
176
6.9
MPAI-x3450SM3xx
353
13.9
MPAI-x4150CM3xx
279
11.0
MPAI-x4150EM3xx
559
22.0
MPAI-x4150RM3xx
279
11.0
MPAI-x4150SM3xx
559
22.0
MPAI-x4300CM3xx
279
11.0
MPAI-x4300EM3xx
559
22.0
MPAI-x4300RM3xx
279
11.0
MPAI-x4300SM3xx
559
22.0
MPAI-x4450CM3xx
245
9.6
MPAI-x4450EM3xx
491
19.3
MPAI-x4450RM3xx
196
7.7
MPAI-x4450SM3xx
393
13.3
MPAI-x5150CM3xx
200
7.9
MPAI-x5150EM3xx
400
15.7
MPAI-x5300CM3xx
200
7.9
MPAI-x5300EM3xx
400
15.7
MPAI-x5450CM3xx
200
7.9
MPAI-x5450EM3xx
400
15.7
