28 MP-Series Heavy Duty Electric Cylinders
Rockwell Automation Publication MPAI-IN001E-EN-P - March 2012
Clevis Mount Dimensions (frame 110)
Clevis Mount Dimensions (frame 144)
Electric Cylinder
Cat. No.
AD
mm (in.)
AM
mm (in.)
ØD
mm (in.)
G1
mm (in.)
G2 (1)
mm (in.)
(1) For MPAI-A/B4xxxxM34C-W actuator, add 46.2 mm (1.82 in.) to dimensions G2, L7, and ZJ.
H
mm (in.)
HD
mm (in.)
MPAI-A/B4150xM32C-W
96.3 (3.79) 61.3 (2.41) 16.01 (0.630) 30.0 (1.18) 130.7 (5.15) 22.0 (0.866) 151.5 (5.96) MPAI-A/B4300xM32C-W
MPAI-A/B4450xM32C-W
Electric Cylinder
Cat. No.
L3
mm (in.)
IN
mm (in.)
L7 (1)
mm (in.)
OT
mm (in.)
P
mm (in.)
WH
mm (in.)
ZJ (1)
mm (in.)
MPAI-A/B4150xM32C-W
1.5
(0.06)
50.3 (1.98)
466.6 (18.37)
94.3 (3.71) 110.5 (4.35) 16.8 (0.66)
422.1 (16.62)
MPAI-A/B4300xM32C-W 619.0 (24.37) 574.5 (22.62)
MPAI-A/B4450xM32C-W 771.4 (30.37) 726.9 (28.62)
Electric Cylinder
Cat. No.
AD
mm (in.)
AM
mm (in.)
ØD
mm (in.)
G1
mm (in.)
G2 (1)
mm (in.)
(1) For MPAI-A/B5xxxxM34C-W actuator, add 51.6 mm (1.82 in.) to dimensions G2, L7, and ZJ.
H
mm (in.)
HD
mm (in.)
MPAI-A/B5150xM32C-W
110.1 (4.33) 74.9 (2.95)
20.02…20.04
(0.788…0.789)
34.0 (1.34) 146.0 (5.75) 27.0 (1.06) 181.9 (7.16) MPAI-A/B5300xM32C-W
MPAI-A/B5450xM32C-W
Electric Cylinder
Cat. No.
L3
mm (in.)
IN
mm (in.)
L7 (1)
mm (in.)
OT
mm (in.)
P
mm (in.)
WH
mm (in.)
ZJ (1)
mm (in.)
MPAI-A/B5150xM32C-W
1.4 (0.06)
60.33
(2.375)
552.6 (21.76)
114.30
(4.500)
143.6 (5.66) 24.1 (0.95)
501.8 (19.76)
MPAI-A/B5300xM32C-W 705.0 (27.76) 654.2 (25.76)
MPAI-A/B5450xM32C-W 857.4 (33.76) 806.6 (31.76)
