MP-Series Heavy Duty Electric Cylinders 25
Rockwell Automation Publication MPAI-IN001E-EN-P - March 2012
Trunnion Mount Dimensions (frame 110)
Trunnion Mount Dimensions (frame 144)
Electric Cylinder
Cat. No.
AD
mm (in.)
AM
mm (in.)
G1
mm (in.)
G2
(1)
mm (in.)
(1) For MPAI-A/B4xxxxM34B actuator, add 46.2 mm (1.88 in.) to dimensions G2, L7, and ZJ.
HD
mm (in.)
L7
(1)
mm (in.)
M
(2)
mm (in.)
(2) The tolerance for this dimension is +0.0, -0.038 mm (+0.0, -0.0015 in.).
L1
mm (in.)
MPAI-A/B4150xM32B
96.3
(3.79)
61.3
(2.41)
30.4
(1.20)
130.7
(5.15)
151.5
(5.96)
466.6
(18.37)
127.0
(5.0)
21.0
(0.83)
MPAI-A/B4300xM32B
619.0
(24.37)
MPAI-A/B4450xM32B
771.4
(30.37)
Electric Cylinder
Cat. No.
L3
mm (in.)
MD
mm (in.)
P
mm (in.)
S
mm (in.)
TB1
mm (in.)
TB2
mm (in.)
WH
mm (in.)
ZJ
(1)
mm (in.)
MPAI-A/B4150xM32B
1.5
(0.06)
22.2
(0.87)
110.5
(4.35)
M8 x 1.25 x12
(0.05 x 0.47)
20.05
(0.79)
6.25
(0.25)
16.8
(0.66)
422.1
(16.62)
MPAI-A/B4300xM32B
574.5
(22.62)
MPAI-A/B4450xM32B
726.9
(28.62)
Electric Cylinder
Cat. No.
AD
mm (in.)
AM
mm (in.)
G1
mm (in.)
G2
(1)
mm (in.)
(1) For MPAI-A/B5xxxxM34B actuator, add 51.5 mm (2.03 in.) to dimensions G2, L7, and ZJ.
HD
mm (in.)
L7
(1)
mm (in.)
M
(2)
mm (in.)
(2) The tolerance for this dimension is +0.0, -0.038 mm (+0.0, -0.0015 in.).
L1
mm (in.)
MPAI-A/B5150xM32B
110.1
(4.33)
74.9
(2.95)
34.4
(1.35)
146.8
(5.78)
181.9
(7.16)
553.4
(21.79)
155.00
(6.10)
28.0
(1.10)
MPAI-A/B5300xM32B
705.8
(27.79)
MPAI-A/B5450xM32B
858.2
(33.79)
Electric Cylinder
Cat. No.
L3
mm (in.)
MD
mm (in.)
P
mm (in.)
S
mm (in.)
TB1
mm (in.)
TB2
mm (in.)
WH
mm (in.)
ZJ
(1)
mm (in.)
MPAI-A/B5150xM32B
1.4
(0.06)
22.2
(0.88)
143.6
(5.66)
M12 x 1.75 x 12
(0.07 x 0.47)
24.9
(0.98)
8.2
(0.32)
24.1
(0.95)
502.6
(19.79)
MPAI-A/B5300xM32B
655.0
(25.79)
MPAI-A/B5450xM32B
807.4
(31.79)
