24 MP-Series Heavy Duty Electric Cylinders
Rockwell Automation Publication MPAI-IN001E-EN-P - March 2012
Trunnion Mount Dimensions (frame 64)
Trunnion Mount Dimensions (frame 83)
Electric Cylinder
Cat. No.
AD
mm (in.)
AM
mm (in.)
G1
mm (in.)
G2
(1)
mm (in.)
(1) If ordering MPAI-A/B2xxxCV34B actuator with brake, add 37.6 mm (1.48 in.) to dimensions G2, L7, and ZJ.
HD
mm (in.)
L7
mm (in.)
M
(2)
mm (in.)
(2) The tolerance for this dimension is +0.0, -0.038 mm (+0.0, -0.0015 in.).
L1
mm (in.)
MPAI-A/B2150CV32B
72.8
(2.87)
41.9
(1.65)
28.8
(1.13)
106.9
(4.21)
104.5
(4.11)
288.0
(11.34)
70.00
(2.756)
15.00
(0.591)
MPAI-A/B2300CV32B
364.2
(14.34)
MPAI-A/B2450CV32B
516.64
(20.34)
Electric Cylinder
Cat. No.
L3
mm (in.)
MD
mm (in.)
P
mm (in.)
S
mm (in.)
TB1
mm (in.)
TB2
mm (in.)
WH
mm (in.)
ZJ
(1)
mm (in.)
MPAI-A/B2150CV32B
1.5 (0.06)
9.5
(0.38)
63.5
(2.50)
M6 x 1.0 x 9
(0.04 x 0.35)
8.7
(0.34)
2.3
(0.09)
17.3
(0.68)
263.5
(10.37)
MPAI-A/B2300CV32B
339.7
(13.37)
MPAI-A/B2450CV32B
492.1
(19.37)
Electric Cylinder
Cat. No.
AD
mm (in.)
AM
mm (in.)
G1
mm (in.)
G2
(1)
mm (in.)
(1) For MPAI-A/B3xxxxM34B actuator, add 47.7 mm (1.88 in.) to dimensions G2, L7, and ZJ.
HD
mm (in.)
L7
(1)
mm (in.)
M
(2)
mm (in.)
(2) The tolerance for this dimension is +0.0, -0.038 mm (+0.0, -0.0015 in.).
L1
mm (in.)
MPAI-A/B3150xM32B
82.8
(3.26)
54.6
(2.15)
30.4
(1.20)
127.5
(5.02)
124.6
(4.90)
413.6
(16.29)
92.0
(3.622)
15.0
(0.59)
MPAI-A/B3300xM32B
566.0
(22.29)
MPAI-A/B3450xM32B
718.4
(28.29)
Electric Cylinder
Cat. No.
L3
mm (in.)
MD
mm (in.)
P
mm (in.)
S
mm (in.)
TB1
mm (in.)
TB2
mm (in.)
WH
mm (in.)
ZJ
(1)
mm (in.)
MPAI-A/B3150xM32B
1.5
(0.06)
16.8
(0.66)
83.6
(3.29)
M8 x 1.25 x12
(0.05 x 0.47)
16.0
(0.63)
3.2
(0.13)
17.3
(0.68)
376.3
(14.81)
MPAI-A/B3300xM32B
528.7
(20.81)
MPAI-A/B3450xM32B
681.1
(26.81)
