Technical Specifications A-1
A
PPENDIX
A
Technical Specifications
Table A.1 – Service Conditions
AC Line Distribution Capacity
(Maximum) 100KVA, single-phase 115VAC and three-phase 230VAC, with 5,000 amps
symmetrical fault current capacity for M/N 1SU1xxxx and1SU2xxxx drives
1000KVA, three-phase 460 and 575VAC, with 30,000amps symmetrical fault
current capacity for M/N 1SU4xxxx and 1SU5xxxx drives
Control Method All-digital, pulse-width-modulated (PWM)
Carrier Frequency 4 kHz, 6 kHz, or 8 kHz, software selectable
Displacement Power Factor 0.96
Line Frequency 50/60 Hz (± 5 Hz)
Line Voltage Variation –10% to +10%
Line Dip RideThrough 500 milliseconds
Linearity 0.05 (Speed reference to output frequency)
Long-term Frequency Stability 0.01%
Minimum Frequency Range 0.5 – 30 Hz
Maximum Frequency Range 30 – 240 Hz
Maximum Load 150% for 1 minute (nominal, based on drive nameplate rating)
Motor Lead Lengths 76 meters (250 feet) total (See table 3.7 for more information)
Overcurrent Trip IET 200% rated drive current
Table A.2 – Dimensions
Enclosure Height Depth Width Weight
A 304.8mm (12.00”) 121.9mm (4.80”) 146.0mm (5.75”) 2.7 kg (6 lb)
B 301.7mm (11.88”) 160.1mm (6.30”) 222.3mm (8.75”) 5.4 kg (12 lb)
C 357.8mm (14.10”) 158.2 mm (6.20”) 278.1mm (10.9”) 8.1 kg (18 lb)
D 465.2mm (18.31”) 198.9mm (7.83”) 286.5mm (11.28”) 15.3 kg (34 lb)
Table A.3 – Environmental Conditions
Operating Temperature 0° to +40°C (32° to 104°F) – enclosed drives
0° to +55°C (32° to 131°F) – open chassis (cover removed)
Storage Temperature – 40° to +65°C (– 40° to +149°F)
Humidity 5 to 95% (non-condensing)
Altitude Do not install the drive above 1000 meters (3300 feet) without derating
output power. For every 91.4 meters (300 feet) above 1000 meters
(3300 feet) up to 3033 meters (10,000 feet), derate the output current by
1%. Above 3033 meters (10,000 feet), contact your local Reliance
Electric sales office for assistance.
