Replacement Parts F-1
A
PPENDIX
F
Replacement Parts
The following tables list the replacement parts available from Reliance Electric.
Replacement parts are not available for 1 and 2 HP drives (M/N 1SU1xxxx and
1SU2xxxx). For M/N 1SU24002, use the replacement parts listed for the 3 HP drive.
Table F.1 – Replacement Parts List for Model 1SU2xxxx Drives
Quantity per Horsepower
Description Part Number 3 HP 5 HP
Fan Assembly 615161-S 2 2
NEMA 4X Cover/Gasket 805522-1R 1 1
NEMA 1 Cover 805508-2R 1 1
Membrane Switch Keypad/Bracket 709511-1R 1 1
Regulator PCB 56952-300 1 1
Capacitor PCB 56931-050 1 1
Fan Assembly (Internal) 615159-1R 1 1
Table F.2 – Replacement Parts List for Model 1SU4xxxx Drives
Part Number
Quantity per Horsepower
Description 1 HP 2 HP 3 HP 5 HP 7.5 HP 10 HP 15 HP 20 HP
Fan Assembly 615161-S – – 1 1 2 2 2 2
NEMA 4X Cover/Gasket 805512-1R
805522-1R 1
– 1
– 1
– 1
– –
1 –
1 –
– –
–
NEMA 1 Cover 805504-7R
805508-9R
805522-20R 1
–
– 1
–
– 1
–
– 1
–
– –
1
– –
1
– –
–
1 –
–
1
NEMA 12 Cover 805512-20R – – – – – – 1 1
Membrane Switch
Keypad/Bracket 709507-1R
709511-1R
709516-1R 1
–
– 1
–
– 1
–
– 1
–
– –
1
– –
1
– –
–
1 –
–
1
Regulator PCB 56953-3xx
56954-3xx 1
– 1
– 1
– 1
– –
1 –
1 –
1 –
1
Capacitor PCB 56928-030
56928-050
56919-070
56919-100
56961
56962 –
–
–
–
–
– –
–
–
–
–
– 1
–
–
–
–
– –
1
–
–
–
– –
–
1
–
–
– –
–
–
1
–
– –
–
1
–
1
– –
–
–
1
–
1
Fan Assembly (Internal) 615159-1R 1 1 1 1 1 1 1 1
Power Supply (Signal) PCB 56957 – – – – – – 1 1
Power PCB 56963 – – – – – – 1 1
Gate Drive PCB 56960 – – – – – – 1 1
IGBT Module 602909-813W – – – – – – 3 3
Diode Bridge 701819-112BA
701819-111BA –
– –
– –
– –
– –
– –
– 1
– –
1
