Rockwell Automation Ethernet Design Considerations Reference Manual User Manual
Page 40
40
Rockwell Automation Publication ENET-RM002C-EN-P - May 2013
Chapter 3
Ethernet Infrastructure Features
Figure 5 - Star with Stratix 5700 Switch
Figure 6 - Redundant Star with Stratix 5700 Switch
Stratix 5700 with NAT
Plant Network
Logix Controller
PanelView
POINT I/O
PowerFlex Drive
Stratix 5700 with NAT
Plant Network
Logix Controller
PanelView
POINT I/O
PowerFlex Drive
