Troubleshooting the PROFIBUS Module and Network 8-5
8.2 Module Diagnostic Items
Table 8.4 lists diagnostic items that can be accessed using
VS Utilities software or the LCD OIM.
Table 8.4 – Module Diagnostic Items
No. Event Description
1 Common Logic
Cmd The current value of the Common Logic
Command being transmitted to the host.
2 Prod Logic Cmd The current value of the Product-specific Logic
Command being transmitted to the host.
3 Reference The current value of the Product-specific
Reference being transmitted to the host.
4 Common Logic Sts The current value of the Common Logic Status
being received from the host.
5 Prod Logic Sts The current value of the Product-Specific Status
being received from the host.
6 Feedback The current value of the Product-Specific
Feedback being received from the host.
7 Datalink A1 In The current value of Datalink A1 being
transmitted to the host. (Value of 0 if datalink is
not used).
8 Datalink A2 In The current value of Datalink A2 being
transmitted to the host. (Value of 0 if datalink is
not used).
9 Datalink B1 In The current value of Datalink B1 being
transmitted to the host. (Value of 0 if Datalink is
not used).
10 Datalink B2 In The current value of Datalink B2 being
transmitted to the host. (Value of 0 if Datalink is
not used).
11 Datalink C1 In The current value of Datalink C1 being
transmitted to the host. (Value of 0 if Datalink not
used).
12 Datalink C2 In The current value of Datalink C2 being
transmitted to the host. (Value of 0 if Datalink is
not used).
13 Datalink D1 In The current value of Datalink D1 being
transmitted to the host. (Value of 0 if Datalink is
not used).
14 Datalink D2 In The current value of Datalink D2 being
transmitted to the host. (Value of 0 if Datalink is
not used).
15 Datalink A1 Out The current value of Datalink A1 being received
from the host.
