Programming Reference
4-53
The status of the digital inputs (selected by entering a value of 1, 2, or 4 in P.090) is
P.090 Diagnostics Source
This parameter is
used to select
internal information
such as I/O data,
network statistics,
etc., for display in
parameter P.091.
Parameter Range:
0 = Diagnostic not used
1 = Terminal strip digital inputs 4, 3, 2, 1
2 = Terminal strip digital inputs 8, 7, 6, 5
3 = Terminal strip analog input normalized to speed
(see Appendix G)
4 = RMI digital inputs 4, 3, 2, 1
5 = RMI analog input (see Appendix G)
6 = RMI frequency input (see Appendix G)
7 = Encoder data
8 = DC bus voltage
9 = Terminal strip analog input scaled (see
Appendix G)
10 = Terminal strip analog input with P.009 (Terminal
Strip Analog Input Offset) applied (see
Appendix G)
11 = Analog input stop threshold (see Appendix G)
12 = Analog input start threshold (see Appendix G)
14 = Network interface: number of messages
received from the network
15 = Network interface: number of message receive
time-out errors
16 = Network interface: number of message CRC
errors
17 = Network interface: number of message overrun
errors
18 = Network interface: number of messages
aborted
19 = Network interface: number of messages
transmitted to the network
Default Setting:
0
Parameter Type:
Tunable
Refer also to parameters:
P.091 Diagnostics Display
P.091 Diagnostics Display
This parameter
displays the data
selected in P090.
Parameter Range:
N/A
Default Setting:
N/A
Parameter Type:
N/A
Refer also to parameters:
P.090 Diagnostics Source
