8-4
Interbus Communications Module
5
Prod Logic Sts
The current value of the Product-Specific Status
being received from the Host.
6
Feedback
The current value of the Product-Specific Feedback
being received from the Host.
7
Datalink A1 In
The current value of Datalink A1 being transmitted
to the Host. (Value of 0 if Datalink is not used).
8
Datalink A2 In
The current value of Datalink A2 being transmitted
to the Host. (Value of 0 if Datalink is not used).
9
Datalink B1 In
The current value of Datalink B1 being transmitted
to the Host. (Value of 0 if Datalink is not used).
10
Datalink B2 In
The current value of Datalink B2 being transmitted
to the Host. (Value of 0 if Datalink is not used).
11
Datalink C1 In
The current value of Datalink C1 being transmitted
to the Host. (Value of 0 if Datalink not used).
12
Datalink C2 In
The current value of Datalink C2 being transmitted
to the Host. (Value of 0 if Datalink is not used).
13
Datalink D1 In
The current value of Datalink D1 being transmitted
to the Host. (Value of 0 if Datalink is not used).
14
Datalink D2 In
The current value of Datalink D2 being transmitted
to the Host. (Value of 0 if Datalink is not used).
15
Datalink A1 Out
The current value of Datalink A1 being received
from the Host.
16
Datalink A2 Out
The current value of Datalink A2 being received
from the Host.
17
Datalink B1 Out
The current value of Datalink B1 being received
from the Host.
18
Datalink B2 Out
The current value of Datalink B2 being received
from the Host.
19
Datalink C1 Out
The current value of Datalink C1 being received
from the Host.
20
Datalink C2 Out
The current value of Datalink C2 being received
from the Host.
21
Datalink D1 Out
The current value of Datalink D1 being received
from the Host.
22
Datalink D2 Out
The current value of Datalink D2 being received
from the Host.
23
Field Flash Cntr
The number of times this device has been flash
updated.
Table 8.6 – Module Diagnostic Items (Continued)
No.
Event
Description
