4-8
Interbus Communications Module
4.5
Viewing the Module Configuration
The parameters in table 4.6 provide information about how the
module is configured. You can view these parameters at any time.
Table 4.6 – Module Configuration Status Parameters
No.
Name and Description
Details
01
DPI Port
Port to which the module is connected. This will
usually be port 5.
Default:
0
Minimum:
0
Maximum:
7
Type:
Read Only
03
Ref/Fdbk Size
Size of the Reference/Feedback. The drive
determines the size of the Reference/Feedback.
Default:
0 = 16-bit
Values:
0 = 16-bit
1 = 32-bit
Type:
Read/Write
04
Datalink Size
Size of each Datalink word. The drive determines
the size of Datalinks.
Default:
0 = 16-bit
Values:
0 = 16-bit
1 = 32-bit
Type:
Read Only
09
DPI I/O Active
I/O that the module is actively transmitting. The
value of this parameter will usually be equal to the
value of parameter 8 - DPI I/O Config.
Default:
xxx0 0001
Bit Values:
0 = I/O disabled
1 = I/O enabled
Type:
Read Only
Bit Definitions
0 = Cmd/Ref
1 = Datalink A
2 = Datalink B
3 = Datalink C
4 = Datalink D
5 = Not Used
6 = Not Used
7 = Not Used
21
PIDD W0 Actual
Actual Process Input Description for Word 0
Displays the Actual PIDD Config being transmitted
to word 0 in the Interbus Master.
Value:
See table 4.2
Type:
Read Only
23
PIDD W1 Actual
Actual Process Input Description for Word 1
Displays the Actual PIDD Config being transmitted
to word 1 in the Interbus Master.
Value:
See table 4.2
Type:
Read Only
25
PIDD W2 Actual
Actual Process Input Description for Word 2
Displays the Actual PIDD Config being transmitted
to word 2 in the Interbus Master.
Value:
See table 4.2
Type:
Read Only
27
PIDD W3 Actual
Actual Process Input Description for Word 3
Displays the Actual PIDD Config being transmitted
to word 3 in the Interbus Master.
Value:
See table 4.2
Type:
Read Only
29
PIDD W4 Actual
Actual Process Input Description for Word 4
Displays the Actual PIDD Config being transmitted
to word 4 in the Interbus Master.
Value:
See table 4.2
Type:
Read Only
31
PIDD W5 Actual
Actual Process Input Description for Word 5
Displays the Actual PIDD Config being transmitted
to word 5 in the Interbus Master.
Value:
See table 4.2
Type:
Read Only
Bit
Default
1
0
0
0
0
x x
x
0
1
2
3
4
5
7
6
