FactoryTalk Historian DataLink User Guide
78
 Click the X and X All buttons to remove selected and all traces,
respectively.
 Click the Rename button to rename a selected trace in the trace
legend.
Specify the Time Range
When the trend traces are determined, the wizard prompts you to specify a
time range for the trend if any of the traces are drawn directly from
FactoryTalk Historian.
To specify a time range:
1. Click in the Start Time and End Time fields, then click to select a
time stamp cell in the spreadsheet.
You can also type a time string directly or use the reference button
to display a reference dialog used to browse and add cell
references.
If you type a combined or absolute time string (page 86), be sure to use
the correct time stamp format.
2. Select Enable Updates to refresh the trend with new FactoryTalk
Historian data if the time range changes or extends to the present.
3. Choose Next or Finish to continue.
