2
●
Basics
●
●
●
●
●
23
When specified, appended data appear in columns (or rows) adjacent to the
primary values returned by a function according to the following rules:
Time data are added in columns to the left (or rows above) primary
values.
Other related data are added in columns to the right (or rows below)
primary values.
Appended Data Array
The following table illustrates how data are appended per function. For
functions that can display output in rows or columns (page 26), substitute
Columns 1-5 with Rows 1-5.
Function Array Columns
Function/Mode
Output Cell
Column 2
Column 3
Column 4
Column 5
Any function without
appended data
value
Current and Archive Value,
Sampled Data
time stamp
value
Compressed Data
time stamp
value
annotations
Time Filtered
start time
end time
value
pct good
Calculated (minimum)
start time
end time
min time
min value
Calculated (maximum)
start time
end time
max time
max value
Calculated (range)
start time
end time
min time
max time
value
Calculated (other)
start time
end time
value
pct good
Alias
server
value
The table assumes all appended data are specified for display, and that some
function arrays can expand to five columns if all related data are appended.
