Tune an axis, Additional resources, Tune an axis additional resources – Rockwell Automation Logix5000 Control System: Connect Kinetix 350 Drives over an EtherNet/IP Network Quick Start User Manual
Page 46
46
Rockwell Automation Publication IASIMP-QS032A-EN-P - March 2012
Chapter 2 Add a Kinetix 350 Drive to an RSLogix 5000 Project
Tune an Axis
For the purposes of this quick start, you do not need to tune the axis. Some applications,
however, require the use of tuning to improve the application’s use of Integrated Motion on an
EtherNet/IP network. Tuning conditions and parameters are defined by each individual
application.
For more information about tuning in an application that uses a Kinetix 350 drive, see the
Kinetix 350 Single-axis EtherNet/IP Servo Drive User Manual, publicatio
.
Additional Resources
For a list of additional resources that might assist you when adding the Kinetix 350 drive to an
RSLogix 5000 project, see
