PowerFlex 70 Parameter Record
Machine #
Date programmed
Drive Serial #
Par Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
126 PI Reference Sel PI Setpoint PI Setpoint
Analog In 1
Analog In 2
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
MOP Level
Master Ref
Preset Spd1
Preset Spd2
Preset Spd3
Preset Spd4
Preset Spd5
Preset Spd6
Preset Spd7
DIP Port 1
DPI Port 2
DPI Port 3
DPI Port 4
DPI Port 5
127 PI Setpoint
-100.00% of Maximum Process
Value + 100% of Maximum Process Value 50.00%
128 PI Feedback Sel PI Setpoint Analog In 2
Analog In 1
Analog In 2
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
MOP Level
Master Ref
Preset Spd1
Preset Spd2
Preset Spd3
Preset Spd4
Preset Spd5
Preset Spd6
Preset Spd7
DIP Port 1
DPI Port 2
DPI Port 3
DPI Port 4
DPI Port 5
129 PI Integral Time 0.00 Secs 100.00 Secs 2.00 Secs
130 PI Prop Gain 0.00 100.00 1.00
131 PI Lower Limit -400.0 Hz +400.0 Hz -[Maximum Freq]
132 PI Upper Limit -400.0 Hz +400.0 Hz +[Maximum Freq]
133 PI Preload -400.0 Hz +400.0 Hz 0.0 Hz
4 of 17
