PowerFlex 70 Parameter Record
Machine #
Date programmed
Drive Serial #
Par Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
134 PI Status PI Enabled 0
PI Hold 0
PI Reset 0
PI InLimit 0
135 PI Ref Meter -100.00 % +100.00 % Read Only
136 PI Fdback Meter -100.00 % +100.00 % Read Only
137 PI Error Meter -100.00 % +100.00 % Read Only
138 PI Output Meter -[Maximum Freq] +[Maximum Freq] Read Only
140 Accel Time 1 0.1 Secs 3600.0 Secs 10.0 Secs
141 Accel Time 2 0.1 Secs 3600.0 Secs 10.0 Secs
142 Decel Time 1 0.1 Secs 3600.0 Secs 10.0 Secs
143 Decel Time 2 0.1 Secs 3600.0 Secs 10.0 Secs
146 S-Curve % 0% 100% 0%
147 Current Lmt Sel Cur Lim Val Cur Lim Val
Analog In 1
Analog In 2
148 Current Lmt Val Based On Drive Rating Based On Drive Rating [Rated Amps] x 1.5
149 Current Lmt Gain 0 5000 250
150 Drive OL Mode Disabled Both-PWM 1st
Reduce CLim
Reduce PWM
Both-PWM 1st
151 PWM Frequency 2 kHz 10 kHz 4 kHz
155 Stop Mode A Coast Ramp
Ramp
Ramp to Hold
DC Brake
156 Stop Mode B Coast Coast
Ramp
Ramp to Hold
DC Brake
157 DC Brk Lvl Sel DC Brake Lvl DC Brake Lvl
Analog In 1
Analog In 2
158 DC Brake Level 0.0 Amps [Rated Amps] x 1.5 [Rated Amps]
159 DC Brake Time 0.0 sec 90.0 sec 0.0 sec
160 Bus Reg Ki 0 5000 450
161 Bus Reg Mode A Disabled Adjust Freq
Adjust Freq
Dynamic Brak
Both-DB 1st
Both-Frq 1st
162 Bus Reg Mode B Disabled Both-Frq 1st
Adjust Freq
Dynamic Brak
Both-DB 1st
Both-Frq 1st
163 DB Resistor Type Internal Res Internal Res
External Res
None
168 Start At PowerUp Disabled Disabled
Enabled
169 Flying Start En Disabled Disabled
Enabled
170 Flying StartGain 20 32767 4000
174 Auto Rstrt Tries 0 9 0
175 Auto Rstrt Delay 0.5 Secs 30.0 Secs 1.0 Secs
184 Power Loss Mode Coast Coast
Decel
185 Power Loss Time 0.0 Secs 60.0 Secs 0.5 Secs
190 Direction Mode Unipolar Unipolar
Bipolar
Reverse Dis
192 Save HIM Ref At Powr Down 1
193 Man Ref Preload Disabled Disabled
Enabled
194 Save MOP Ref At Powr Down 0
At Stop 0
195 MOP Rate 0.2 Hz/s [Maximum Freq] 1.0 Hz/s
196 Param Access Lvl Basic Basic
Advanced
197 Reset To Defalts Ready Ready
Factory
Low Voltage
High Voltage
