Par Parameter Name Factory Default Programmed Value Par Parameter Name Factory Default Programmed Value
273 Drive Ramp Rslt Read Only 1 Output Freq Read Only
276 Logic Mask 1 2 Commanded Freq Read Only
277 Start Mask 1 3 Output Current Read Only
278 Jog Mask 1 4 Torque Current Read Only
279 Direction Mask 1 5 Flux Current Read Only
280 Reference Mask 1 6 Output Voltage Read Only
281 Accel Mask 1 7 Output Power Read Only
282 Decel Mask 1 8 Output Powr Fctr Read Only
283 Fault Clr Mask 1 9 Elapsed MWh Read Only
284 MOP Mask 1 10 Elapsed Run Time Read Only
285 Local Mask 1 11 MOP Frequency Read Only
288 Stop Owner 1 12 DC Bus Voltage Read Only
289 Start Owner 1 13 DC Bus Memory Read Only
290 Jog Owner 1 16 Analog In1 Value Read Only
291 Direction Owner 1 17 Analog In2 Value Read Only
292 Reference Owner 1 26 Rated kW Read Only
293 Accel Owner 1 27 Rated Volts Read Only
294 Decel Owner 1 28 Rated Amps Read Only
295 Fault Clr Owner 1 29 Control SW Ver Read Only
296 MOP Owner 1 40 Motor Type Induction
297 Local Owner 1 41 Motor NP Volts Based on Drive Rating
300 Data In A1 0 42 Motor NP FLA Based on Drive Rating
301 Data In A2 0 43 Motor NP Hertz Based on Drive Cat. No.
302 Data In B1 0 44 Motor NP RPM 1750 RPM
303 Data In B2 0 45 Motor NP Power Based on Drive Rating
304 Data In C1 0 46 Mtr NP Pwr Units Based on Drive Rating
305 Data In C2 0 47 Motor OL Hertz Motor NP Hz/3
306 Data In D1 0 48 Motor OL Factor 1.00
307 Data In D2 0 53 Torque Perf Mode Sensris Vect
310 Data Out A1 0 54 Maximum Voltage Drive Rated Volts
311 Data Out A2 0 55 Maximum Freq 110.0 or 130.0 Hz
312 Data Out B1 0 56 Compensation 1
313 Data Out B2 0 57 Flux Up Mode Manual
314 Data Out C1 0 58 Flux Up Time 0.00 secs
315 Data Out C2 0 59 SV Boost Filter 500
316 Data Out D1 0 61 Autotune Calculate
317 Data Out D2 0 62 IR Voltage Drop Based on Drive Rating
320 Anlg In Config 0 63 Flux Current Ref Based on Drive Rating
321 Anlg In Sqr Root 0 64 Ixo Voltage Drop Based on Drive Rating
322 Analog In 1 Hi 10.0 Volt 69 Start/Acc Boost Based on Drive Rating
323 Analog In 1 Lo 0.0 Volt 70 Run Boost Based on Drive Rating
324 Analog In 1 Loss Disabled 71 Break Voltage [Motor NP Volts] x 0.25
325 Analog In 2 Hi 10.0 Volt 72 Break Frequency [Motor NP Freq] x 0.25
326 Analog In 2 Lo 0.0 Volt 80 Speed Mode Open Loop
327 Analog In 2 Loss Disabled 81 Minimum Speed 0.0 Hz
340 Anlg Out Config 1 82 Maximum Speed 50.0 or 60.0 Hz (Depend on voltage class)
341 Anlg Out Absolut 1 83 Overspeed Limit 10.0 Hz
342 Analog Out1 Sel Output Freq 84 Skip Frequency 1 0.0 Hz
343 Analog Out1 Hi 10.00 Volt 85 Skip Frequency 2 0.0 Hz
344 Analog Out1 Lo 0.00 Volt 86 Skip Frequency 3 0.0 Hz
361 Digital In1 Sel Stop - CF 87 Skip Freq Band 0.0 Hz
362 Digital In2 Sel Start 90 Speed Ref A Sel Analog In 2
363 Digital In3 Sel Auto/Manual 91 Speed Ref A Hi [Maximum Speed]
364 Digital In4 Sel Speed Sel 1 92 Speed Ref A Lo 0.0 Hz
365 Digital In5 Sel Speed Sel 2 93 Speed Ref B Sel Preset Spd1
366 Digital In6 Sel Speed Set 3 94 Speed Ref B Hi [Maximum Speed]
380 Digital Out1 Sel Fault 95 Speed Ref B Lo 0.0 Hz
381 Dig Out1 Level 0.0 96 TB Man Ref Sel Analog In 1
382 Dig Out1 OnTime 0.00 Secs 97 TB Man Ref Hi [Maximum Speed]
383 Dig Out1 OffTime 0.00 Secs 98 TB Man Ref Lo 0.0 Hz
384 Digital Out2 Sel Run 100 Jog Speed 10.0 Hz
385 Dig Out2 Level 0.0 101 Preset Speed 1 5.0 Hz
386 Dig Out2 OnTime 0.00 Secs 102 Preset Speed 2 10.0 Hz
387 Dig Out2 OffTime 0.00 Secs 103 Preset Speed 3 20.0 Hz
