PowerFlex 70 Parameter Record
Machine #
Date programmed
Drive Serial #
Par Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
294 Decel Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
295 Fault Clr Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
296 MOP Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
297 Local Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
300 Data In A1 0 387 0
301 Data In A2 0 387 0
302 Data In B1 0 387 0
303 Data In B2 0 387 0
304 Data In C1 0 387 0
305 Data In C2 0 387 0
306 Data In D1 0 387 0
307 Data In D2 0 387 0
310 Data Out A1 0 387 0
311 Data Out A2 0 387 0
312 Data Out B1 0 387 0
313 Data Out B2 0 387 0
314 Data Out C1 0 387 0
315 Data Out C2 0 387 0
316 Data Out D1 0 387 0
317 Data Out D2 0 387 0
320 Anlg In Config Analog In 1 0
Analog In 2 0
321 Anlg In Sqr Root Analog In 1 0
Analog In 2 0
322 Analog In 1 Hi 4.000 mA 20.000 mA 10.0 Volt
-10.0 V +10.0 V
0.0V 10.0 V
323 Analog In 1 Lo 4.000 mA 20.000 mA 0.0 Volt
-10.0V +10.0V
0.0V 10.0V
