PowerFlex 700 Parameter Record
Machine #
Date programmed
Drive Serial #
Par Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
117 Trim In Select Analog In 1 Analog In 2
Analog In 2
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
MOP Level
Reserved
Preset Spd1
Preset Spd2
Preset Spd3
Preset Spd4
Preset Spd5
Preset Spd6
Preset Spd7
DPI Port 1
DPI Port 2
DPI Port 3
DPI Port 4
DPI Port 5
118 Trim Out Select Trim Ref A 0
Trim Ref B 0
119 Trim Hi - [Maximum Speed] + [Maximum Speed] 60.0 Hz
120 Trim Lo - [Maximum Speed] + [Maximum Speed] 0.0 Hz
121 Slip RPM @ FLA 0.0 RPM 1200.0 RPM Based on [Motor NP RPM]
122 Slip Comp Gain 1.0 100.0 40.0
123 Slip RPM Meter 0.0 RPM 300.0 RPM Read Only
124 PI Configuration Excl Mode 0
Invert Error 0
Preload Mode 0
Ramp Ref 0
Zero Clamp 0
Feedbak Sqrt 0
125 PI Control PI Enable 0
PI Hold 0
PI Reset 0
126 PI Reference Sel PI Setpoint PI Setpoint
Analog In 1
Analog In 2
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
MOP Level
Master Ref
Preset Spd1
Preset Spd2
Preset Spd3
Preset Spd4
Preset Spd5
Preset Spd6
Preset Spd7
DIP Port 1
DPI Port 2
DPI Port 3
DPI Port 4
DPI Port 5
127 PI Setpoint
-100.00% of Maximum Process
Value + 100% of Maximum Process Value 50.00%
3 of 17
