PowerFlex 700 Parameter Record
Machine #
Date programmed
Drive Serial #
Par Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
1 Output Freq - [Maximum Freq] + [Maximum Freq] Read Only
2 Commanded Freq - [Maximum Speed] + [Maximum Speed] Read Only
3 Output Current 0.0 Amps Drive Rated Amps x 2 Read Only
4 Torque Current Drive Rating x -2 Drive Rating x +2 Read Only
5 Flux Current Drive Rating x -2 Drive Rating x +2 Read Only
6 Output Voltage 0.0 VAC Drive Rated Volts Read Only
7 Output Power 0.0 kW Drive Rated kW x 2 Read Only
8 Output Powr Fctr 0.00 1.00 Read Only
9 Elapsed MWh 0.0 MWh 429496729.5 MWh Read Only
10 Elapsed Run Time 0.0 Hrs 429496729.5 Hrs Read Only
11 MOP Frequency - [Maximum Frequency] + [Maximum Frequency] Read Only
12 DC Bus Voltage Based on Drive Rating Based on Drive Rating Read Only
13 DC Bus Memory Based on Drive Rating Based on Drive Rating Read Only
16 Analog In1 Value
0.000 mA
-10.000V
20.000 mA
+10.000V Read Only
17 Analog In2 Value
0.000 mA
-10.000V
20.000 mA
+10.000V Read Only
26 Rated kW 0.37 kW 15.0 kW Read Only
27 Rated Volts Based on Drive Rating Based on Drive Rating Read Only
28 Rated Amps 1.1 Amps 32.2 Amps Read Only
29 Control SW Ver 0.000 65.256 Read Only
40 Motor Type Induction Induction
Synchr Reluc
Synchr PM
41 Motor NP Volts 0.0 VAC [Rated Volts] Based on Drive Rating
42 Motor NP FLA 0.0 Amps [Rated Amps] x 2 Based on Drive Rating
43 Motor NP Hertz 5.0 Hz 400.0 Hz Based on Drive Cat. No.
44 Motor NP RPM 60 RPM 24000 RPM 1750 RPM
45 Motor NP Power 0.0 100.0 Based on Drive Rating
46 Mtr NP Pwr Units Horsepower Based on Drive Rating
kiloWatts
47 Motor OL Hertz 0.0 Hz Motor NP Hz Motor NP Hz/3
48 Motor OL Factor 0.20 2.00 1.00
53 Torque Perf Mode Sensrls Vect Sensris Vect
SV Economize
Custom V/Hz
Fan/Pmp V/Hz
54 Maximum Voltage Rated Volts x 0.25 Rated Volts x 1.0 Drive Rated Volts
55 Maximum Freq 5.0 Hz 400.0 Hz 110.0 or 130.0 Hz
56 Compensation Reflect Wave 1
Enable Jerk 1
57 Flux Up Mode Manual Manual
Automatic
58 Flux Up Time 0.00 secs 5.00 secs 0.00 secs
61 Autotune Ready Calculate
Static Tune
Rotate Tune
Calculate
62 IR Voltage Drop 0.0 VAC [Motor NP Volts] x 0.25 Based on Drive Rating
63 Flux Current Ref 0.00 Amps [Motor NP FLA] Based on Drive Rating
69 Start/Acc Boost 0.0 VAC [Motor NP Volts] x 0.25 Based on Drive Rating
70 Run Boost 0.0 VAC [Motor NP Volts] x 0.25 Based on Drive Rating
71 Break Voltage 0.0 VAC [Motor NP Volts] [Motor NP Volts] x 0.25
72 Break Frequency 0.0 Hz [Motor NP Freq] [Motor NP Freq] x 0.25
80 Speed Mode Open Loop Open Loop
Slip Comp
Process PI
81 Minimum Speed 0.0 Hz [Maximum Speed] 0.0 Hz
82 Maximum Speed 5.0 Hz 400.0 Hz
50.0 or 60.0 Hz (Dependent
on voltage class)
83 Overspeed Limit 0.0 Hz 20.0 Hz 10.0 Hz
84 Skip Frequency 1 - [Maximum Speed] + [Maximum Speed] 0.0 Hz
85 Skip Frequency 2 - [Maximum Speed] + [Maximum Speed] 0.0 Hz
86 Skip Frequency 3 - [Maximum Speed] + [Maximum Speed] 0.0 Hz
87 Skip Freq Band 0.0 Hz 30.0 Hz 0.0 Hz
1 of 17
