PowerFlex 70 Parameter Record
Machine #
Date programmed
Drive Serial #
Par Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
228 Status 2 @ Fault Ready 0
Active 0
Running 1
Jogging 1
Stopping 0
DC Braking 0
AutoTuning 0
Unused X
AutoRst Ctdn 0
Auto Rst Act 1
Curr Limit 1
Bus Freq Reg 1
Motor Overld 0
DPI at 500 k 0
Unused X
Unused X
229 Alarm 1 @ Fault Prechrg Actv 0
UnderVoltage 0
Power Loss 0
Str At PwrUp 0
Anlg In Loss 0
IntDBRes OH 0
Unused X
Drv OL Lvl 1 0
Drv OL Lvl 2 0
Decel Inhibt 0
230 Alarm 2 @ Fault DigIn CflctA 0
DigIn CflctB 0
DigIn CflctC 0
Bipolr Cflct 0
MtrTyp Cflct 0
NP Hz Cflct 0
MaxFrq Cflct 0
VHz NegSlope 0
IR Vlts Rang 0
FlxAmps Rang 0
SpdRef Cflct 0
Unused X
Unused X
Unused X
Unused X
Unused X
234 Testpoint 1 Sel 0 999 499
235 Testpoint 1 Data 0 65535 Read Only
236 Testpoint 2 Sel 0 999 499
237 Testpoint 2 Data 0 65535 Read Only
238 Fault Config 1 Power Loss 0
UnderVoltage 1
Unused X
Motor OverLd 1
Shear Pin 0
AutRst Tries 0
Decel Inhibt 1
240 Fault Clear Ready Ready
Clear Faults
Clr Flt Que
241 Fault Clear Mode Disabled Enabled
Enabled
242 Power Up Marker 0.0000 Hr 429496.7295 Hr Read Only
243 Fault 1 Code 0000 9999 Read Only
244 Fault 1 Time 0.0000 Hr. 429496.7295 Hr. Read Only
245 Fault 2 Code 0000 9999 Read Only
246 Fault 2 Time 0.0000 Hr. 429496.7295 Hr. Read Only
247 Fault 3 Code 0000 9999 Read Only
248 Fault 3 Time 0.0000 Hr. 429496.7295 Hr. Read Only
249 Fault 4 Code 0000 9999 Read Only
250 Fault 4 Time 0.0000 Hr. 429496.7295 Hr. Read Only
259 Alarm Config 1 Prechrg Actv 1
UnderVoltage 1
PowerLoss 1
Str At PwrUp 1
Anlg In Loss 1
IntDBRes OH 1
Unused X
Drv OL Lvl 1 1
Drv OL Lvl 2 1
Decel Inhibt 1
270 DPI Baud Rate 125 kbps 125 kbps
500 kbps
271 Drive Logic Rslt Stop 0
Start 0
Jog 1
Clear Fault 1
Forward 0
Reverse 0
Local Contrl 0
Mop Inc 1
Accel 1 0
Accel 2 1
Decel 1 1
Decel 2 1
Spd Ref ID 0 0
Spd Ref ID 1 0
Spd Ref ID 2 0
MOP Dec 0
272 Drive Ref Rslt 0 32767 Read Only
273 Drive Ramp Rslt 0 32767 Read Only
276 Logic Mask Digital In 1
DPI Port 1 1
DPI Port 2 1
DPI Port 3 1
Unused X
DPI Port 5 1
277 Start Mask Digital In 1
DPI Port 1 1
DPI Port 2 1
DPI Port 3 1
Unused X
DPI Port 5 1
278 Jog Mask Digital In 1
