MicroView Special Controller Functions C-3
Reading Controller Input
and Output Files To read the contents of controller Input and Output files:
The input and output files are read–only files. You can view the data
fields but can not change them.
1. Select item [1] P-A/D from the Special Menu to access the P-A/D
function.
You are prompted for a file type:
2. Press [NEXT] and [PREV] keys to scroll through the file types.
3. Select either Input or Output and press [ ].
If you selected an Input file type, you are prompted to enter the
element number [0 or 1] and press [
] to view the data in that
address element.
If you selected an Output file type, the MicroView displays the
data at element 0 (Zero).
Initially, you are shown the decimal value at that address
element. If you press [NEXT], the hexadecimal format is
displayed:
Pressing [NEXT] again displays the binary value:
4. To exit, press the [CE] key to return to the initial P-A/D screen.
You can press the [CE] key at any time during the P-A/D
function.
5. You can press the [MENU] key at any time to exit the P-A/D
function and display the Main Menu.
Select File Type:
O (Output)
Select File Type:
(I) Input
0 - 1
Select File Type:
O (Output)
Data Format
Data
File=11
Eleml001 DEC
19774
File=l1
Elem=001 HEX
4D3E
File=11
0011111001001101 Elem=001
