1 Publication 2707-UM005B-EN-P
Appendix
A
Specifications
MicroView Specifications
LCD Display
Character Size (H x W) 0.22 x 0.12 in (5.56 x 2.96 mm)
Character Format 5 x 7 dot matrix
Column and Character 2 lines x 16 characters
Backlight Yellow-green LED, fixed intensity
Contrast Fixed
Display Viewing Area (H x W) 0.58 x 2.35 in (15mm x 60 mm)
Viewing Angle Horizontal ± 30
°
, Vertical –20
°
to +30
°
Keypad
Keypad Type Tactile embossed, domed keys, sealed
membrane
Operation Force 16 oz. (453 grams)
Operational Life 1 million operations
Electrical
Communications Port RS-232
Communication Distances 50 ft. (15 meters) maximum
Input Voltage Range 11-25 VDC, 1.5 Watt
Input Current 140 mA at 11 Volts
60 mA at 25 Volts
Environmental
Operating Temperature 0 to 55×C (32 to 131° F)
Storage Temperature -20 to 70° C (-4 to 158° F)
Relative Humidity 5 to 95%, non-condensing
Shock 30G operating
50G non-operating
Agency Rating UL, CSA, CE
Mechanical (Catalog # 2707-MVH232, Hand-Held)
Dimensions (Approximate)
Height: 5.1 inch (129.5 mm)
Width: 3.55 inch (90.2 mm)
Depth: 0.975 inch (24.8 mm)
