26 Fiber Optic Cable Installation and Handling Instructions
Publication 2090-IN010C-EN-P – April 2005
2090-SCEP32-0
32, (1260)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP0-1
0.1, (4)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP0-3
0.3, (12)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP0-9
0.9, (35)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP1-0
1, (39)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP3-0
3, (118)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP5-0
5, (197)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP8-0
8, (315)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP10-0
10, (394)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP15-0
15, (591)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP20-0
20, (787)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP25-0
25, (984)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCNP32-0
32, (1260)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCVP0-1
0.1, (4)
40.0 (1.6)
< 245 (55)
0.4 N·m
5
2090-SCVP0-3
0.3, (12)
40.0 (1.6)
< 245 (55)
0.4 N·m
5
2090-SCVP0-9
0.9, (35)
40.0 (1.6)
< 245 (55)
0.4 N·m
5
2090-SCVP1-0
1, (39)
40.0 (1.6)
< 245 (55)
0.4 N·m
5
2090-SCVP3-0
3, (118)
40.0 (1.6)
< 245 (55)
0.4 N·m
5
2090-SCVP5-0
5, (197)
40.0 (1.6)
< 245 (55)
0.4 N·m
5
2090-SCVP8-0
8, (315)
40.0 (1.6)
< 245 (55)
0.4 N·m
5
2090-SCVP10-0
10, (394)
40.0 (1.6)
< 245 (55)
0.4 N·m
5
2090-SCVP15-0
15, (591)
40.0 (1.6)
< 245 (55)
0.4 N·m
5
Catalog
Number
Length
meters,
(inches)
Long Term
Bend
Radius
No Load
mm (in.)
Maximum
Tensile
Load
Newtons
(Lbs.)
Impact
Twist
(times)
