Fiber Optic Cable Installation and Handling Instructions 25
Publication 2090-IN010C-EN-P – April 2005
Fiber Optic Cable Specifications
Hard Clad Silica Glass Fiber Optic Cable Mechanical Limits
*Highly susceptible to fracture under twisting load.
Plastic Fiber Optic Cable Mechanical Limits
Catalog
Number
Length
meters,
(inches)
Long Term
Bend
Radius
No Load
mm (in.)
Maximum
Tensile
Load
Newtons
(Lbs.)
Impact
Twist
(times)
2090-SCVG50-0
50, (1970)
30 (1.2)
<98 (22)
490 N/5 cm
Avoid*
2090-SCVG100-0
100, (3937)
30 (1.2)
<98 (22)
490 N/5 cm
Avoid*
2090-SCVG150-0
150, (5905)
30 (1.2)
<98 (22)
490 N/5 cm
Avoid*
2090-SCVG200-0
200, (7874)
30 (1.2)
<98 (22)
490 N/5 cm
Avoid*
Catalog
Number
Length
meters,
(inches)
Long Term
Bend
Radius
No Load
mm (in.)
Maximum
Tensile
Load
Newtons
(Lbs.)
Impact
Twist
(times)
2090-SCEP0-1
0.1, (4)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCEP0-3
0.3, (12)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCEP0-9
0.9, (35)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCEP1-0
1, (39)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCEP3-0
3, (118)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCEP5-0
5, (197)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCEP8-0
8, (315)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCEP10-0
10, (394)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCEP15-0
15, (591)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCEP20-0
20, (787)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
2090-SCEP25-0
25, (984)
25.4 (1.0)
< 70 (15)
0.4 N·m
5
