14 Fiber Optic Cable Installation and Handling Instructions
Publication 2090-IN010C-EN-P – April 2005
Catalog Number Length meters,
(inches) Maximum
Attenuation
(dB) Maximum
Attenuation
With Bulkhead
Conn.
2090-SCVP0-1 0.1, (4) 2.02 5.02
2090-SCVP0-3 0.3, (12) 2.06 5.06
2090-SCVP0-9 0.9, (35) 2.17 5.17
2090-SCVP1-0 1, (39) 2.19 5.19
2090-SCVP3-0 3, (118) 2.57 5.57
2090-SCVP5-0 5, (197) 2.95 5.95
2090-SCVP8-0 8, (315) 3.52 6.52
2090-SCVP10-0 10, (394) 3.90 6.90
2090-SCVP15-0 15, (591) 4.85 7.85
2090-SCVP20-0 20, (787) 5.80 8.80
2090-SCVP25-0 25, (984) 6.75 9.75
2090-SCVP32-0 32, (1260) 8.08 11.08
