Publication 2727-UM002D-EN-P
3-16 Terminal Connections
Installing the Mounting
Bracket The MobileView Mounting Bracket (2727-MRMB1) is used for
stationary operation or storage of the MobileView terminal. The
following illustration shows the mounting bracket with and without
the terminal mounted.
The carrier is adjustable in 8 positions over a height of 320 mm (12.60
in). It is important to attach the carrier at all 4 points on the height
adjustment plate. Mount the cable holder on the carrier using the
screws shipped with the bracket.
Use suitable screws (not shipped with product) to mount the height
adjustment plate.
Carrier
MobileView
Connection
Cable
Holder
120 mm (4.72 in)
52
6 m
m
(2
0.
71
in
)
55
0 m
m
(2
1.
65
in
)
6 mm
dia. (
0.24 i
n)
12
m
m
d
ia
. (0
.4
7 i
n)
12
m
m
(0
.4
7 in
) 150 mm (5.91 in) 28 mm (1
.1
in
)
22 mm (0.87 in)
20
mm
(0
.7
9 in
)
Height Adjustment Plate
Dimensions and Mounting Holes
