Chapter 7
Programming
7–41
The addresses for the Input and Output files are provided in an octal format.
You must convert the bit addresses to decimal to accommodate the
SLC–5/02. Refer to the following.
Bit Address
Decimal
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
SLC–5/02
Octal
1
2
3
4
5
6
7
10
11
12
13
14
15
16
17
PLC–5
The BAUD rate is 115.2K. DIP switch 1 should be in the OFF position, DIP
switch 2 should be ON.
The G file size is set to 3 using the Speciality I/O Configuration function.
The M0 and M1 file sizes are set to 32 in the Advanced Set Up function.
Since only the first four words of the input and output files contain valid
information, the scanned input and output words can be set to 4. Reducing
the number of scanned input and output words decreases your SLC scan
time.
Address Conversion
Scanner Configuration
