Programming Examples

Appendix B

BĆ5

Figure B.3

Sample PLC-5 Data File (Hexidecimal Data)

Address
N7:60
N7:70

3

0150
0000

5

0150

6

0150

7

0150

8

0000

9

0000

4

0150

2

0150
0000

1

0976
0000

0

5141
0000

The above data file would configure the module as follow:

copper RTDs on all inputs

temperature scale of Fahrenheit

channel 1 displayed in ohms

output data in BCD format

real time sampling set to a 1 second scan rate

copper RTD at 25

o

C is 9.76 ohms

all bias values set to subtract 0150

all calibration values set to 0

3.

Enter the data corresponding to your bit selections.

4.

[ESC] returns you to the main menu.
