Programming Examples
Appendix B
BĆ2
In PROG Mode
Action Result
1. Press [SEARCH]8 Finds the block transfer instruction
2. Press CANCEL COMMAND Removes preceeding command
3. Press [DISPLAY]0 or 1 Displays the file in binary or BCD
4. Press [DISPLAY]001 and enter data Puts cursor on word 1
5. Press [INSERT]
Use the above procedure to enter the required words of the write block transfer
instruction. Be aware that the block length will depend on the number of
channels selected and whether biasing and/or calibration is or is not performed;
for example, the block may contain only 1 word if no bias or calibration is
performed but may contain 14 words if using 6 inputs with bias and calibration.
The PLC–2 family write block transfer data file should look like Figure B.1.
Figure B.1
Write Block Transfer Data Transfer for a PLC-2 Family Processor
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000 00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000 001
002
003
004
005
006
007
008
POSITION FILE DATA
DATA ADDR: 030 BINARY DATA MONITOR BLOCK LENGTH: 14
BLOCK XFER WRITE
MODULE ADDR: 110
FILE: 100-115
