Publication 1747-UM002A-US-P - June 2000
Overview 1-9
5. Click on Continue.
6. If the development files were selected in the last dialog, the next
dialog allows a destination directory to be specified. Click on
Continue after you select the directory.
7. The necessary files are copied to the disk, and the system
registry is updated to include the OCdriver information.
8. Press OK to exit the setup utility. The contents of the
temporary directory can now be deleted.
The Windows NT API uses these files:
Installation Details
This section describes the actions the setup utility performs to install
the API and OCdriver.
If you select Runtime (Complete), the setup utility:
1. copies the device driver file, OCdriver , to the system device
driver directory ( %SystemRoot%\system32\drivers ).
IMPORTANT
You must shutdown and reboot the scanner before
using the API. (The setup utility sets the registry Start
parameter for OCdriver to Automatic; therefore, the
service manager starts the OCdriver when the system
is booted.)
This file: Contains:
ocapi.lib Import library in Microsoft COFF format
ocapi.h API header file that contains API-referenced structures
ocapi.dll API DLL
sample.c Sample application program calling the API functions
sampleb.mak Sample make file for the Borland C compiler
samplem.mak Sample make file for the Microsoft C compiler
