CompactLogix Analog Output Module 31
Rockwell Automation Publication 1769-IN089A-EN-P - March 2011
Output Data
1769-OF8C and 1769-OF8V Output Data
Local:1:O
AB:1769_OF8C:O:0 / AB:1769_OF8V:O:0
+
Local:1:O.Ch0Data
INT
Decimal
+
Local:1:O.Ch1Data
INT
Decimal
+
Local:1:O.Ch2Data
INT
Decimal
+
Local:1:O.Ch3Data
INT
Decimal
+
Local:1:O.Ch4Data
INT
Decimal
+
Local:1:O.Ch5Data
INT
Decimal
+
Local:1:O.Ch6Data
INT
Decimal
+
Local:1:O.Ch7Data
INT
Decimal
+
Local:1:O.AlarmUnlatch
INT
Binary
Local:1:O.Ch0OverRangeUnlatch
BOOL
Decimal
Local:1:O.Ch0UnderRangeUnlatch
BOOL
Decimal
Local:1:O.Ch1OverRangeUnlatch
BOOL
Decimal
Local:1:O.Ch1UnderRangeUnlatch
BOOL
Decimal
Local:1:O.Ch2OverRangeUnlatch
BOOL
Decimal
Local:1:O.Ch2UnderRangeUnlatch
BOOL
Decimal
Local:1:O.Ch3OverRangeUnlatch
BOOL
Decimal
Local:1:O.Ch3UnderRangeUnlatch
BOOL
Decimal
Local:1:O.Ch4OverRangeUnlatch
BOOL
Decimal
Local:1:O.Ch4UnderRangeUnlatch
BOOL
Decimal
Local:1:O.Ch5OverRangeUnlatch
BOOL
Decimal
Local:1:O.Ch5UnderRangeUnlatch
BOOL
Decimal
Local:1:O.Ch6OverRangeUnlatch
BOOL
Decimal
Local:1:O.Ch6UnderRangeUnlatch
BOOL
Decimal
Local:1:O.Ch7OverRangeUnlatch
BOOL
Decimal
Local:1:O.Ch7UnderRangeUnlatch
BOOL
Decimal
