RSLogix 5000 Controller Tags
Use the following controller tags with RSLogix 5000 software, version 15 and
later.
Program (Idle)
Mode Hold Last State
(1)
0 0 0 0 0 0 0 0 0
User-Defined
Value
(1)
0 0 0 0 0 0 0 0 1
Fault Mode Hold Last State
(1)
0 0 0 0 0 0 0 0 0
User-Defined Fault
Value
(1)
0 0 0 0 0 0 0 0 1
Enable
Ramping Disabled 0 0 0 0 0 0 0 0 0
Enabled 0 0 0 0 0 0 0 0 1
System
Interrupt High
Clamp Disabled 0 0 0 0 0 0 0 0 0
Enabled 0 0 0 0 0 0 0 0 1
System
Interrupt Low
Clamp Disabled 0 0 0 0 0 0 0 0 0
Enabled 0 0 0 0 0 0 0 0 1
Enable
Channel Disabled 0 0 0 0 0 0 0 0 0
Enabled 1 0 0 0 0 0 0 0 0
(1) These functions are not supported by all controllers (for example, MicroLogix 1500) using any configuration method.
Refer to your controller manual for details.
Define Indicate this These bit settings
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Output Range
Select 0 to 20 mA DC 0 0 0 0 0 0 0 0 0 0 0 0 0
4 to 20 mA DC 0 0 0 0 0 0 0 0 0 0 0 0 1
Output Data
Select Raw/proportional
Counts 0 0 0 0 0 0 0 0 0 0 0 0 0
Engineering Units 0 0 0 0 0 0 0 1 0 0 0 0 0
Scaled for PID 0 0 0 0 0 0 1 0 0 0 0 0 0
Percent Range 0 0 0 0 0 0 1 1 0 0 0 0 0
Define Indicate this These bit settings
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
