10 CompactLogix Analog Output Module
Rockwell Automation Publication 1769-IN089A-EN-P - March 2011
5. Place the modules back on the panel, and check for proper hole
alignment.
6. Attach the modules to the panel by using the mounting screws.
7. Repeat steps 1 … 6 for any remaining modules.
DIN Rail Mounting
The module can be mounted using the following DIN rails: 35 x 7.5 mm (EN
50 022 - 35 x 7.5) or 35 x 15 mm (EN 50 022 - 35 x 15).
Before mounting the module on a DIN rail, close the DIN rail latches. Press
the DIN rail mounting area of the module against the DIN rail. The latches
will momentarily open and lock into place.
Replacing a Single Module within a System
The module can be replaced while the system is mounted to a panel (or DIN
rail). Follow the steps below:
1. Remove power.
See important note on page 6 .
2. On the module to be removed, remove the upper and lower mounting
screws from the module (or open the DIN latches using a flat-blade or
phillips-style screwdriver).
3. Move the bus lever to the right to disconnect (unlock) the bus.
TIP If mounting more modules, mount only the last one of this group and put
the others aside. This reduces remounting time during drilling and
tapping of the next group.
ATTENTION: During panel or DIN rail mounting of all devices, be sure that
all debris (such as metal chips and wire strands is kept from falling into the
module. Debris that falls into the module could cause damage on power
up.
