Publication 1734-UM008B-EN-P - August 2005
A-36 1734-POINT I/O Module/RSLogix5000 Controller Tag Reference
Compare 0,1 Value Note:
To enter Compare values from +2,147,483,647 to +4,294,967,295, use
this conversion formula:
Desired Compare Value - 4,294,967,296 = Entered Compare
Value.
Example: For a 3,000,000,000 compare value,
3,000,000,000 - 4,294,967,296 = -1,294,967,296
1734-SSI
1 Channel Synchronous Serial Interface
Input Data Data Type Default
Value Valid Data Values
Present Data DINT 0 -2,147,483,648 to
2,147,483,647
(0 - 4,294,967,295)
Latched Data DINT 0 -2,147,483,648 to
2,147,483,647
(0 - 4,294,967,295)
Status
Input Status
Run
Decreasing Count
Increasing Count
Compare0 Reached
Compare1 Reached
Compare0 Status
Compare1 Status
Power Fault
Configuration Fault
Communication Fault
Input Data Fault
Data Latched
INT
BIT 0
BIT 1
BIT 2
BIT 3
BIT 4
BIT 5
BIT 6
BIT 7
BIT 8
BIT 9
BIT 10
BIT 11
BIT 12
0
0=Input is Off
1=Input is On
0=Module is not Running
1=Module is Running
0=Count not Decreasing
1=Count is Decreasing
0=Count not Increasing
1=Count is Increasing
0=Compare not Reached
1=Compare was Reached
0=Compare Off
1=Compare On
0=No 24Vdc Power Fault
1=24Vdc Power Fault
0=No FPGA Config Fault
1=FPGA Config data bad
0=No FPGA Comm Fault
1=FPGA Comm Fault
0=No Input Data Fault
1=Input Power Fault (short)
0=Input Data Not Latched
1=Input Data Latched
