Select the 1734-acnr adapter – Rockwell Automation 1734-ACNR POINT I/O ControlNet Adapter User Manual User Manual
Page 36
Publication 1734-UM008B-EN-P - August 2005
4-6 Configure the Adapter
Select the 1734-ACNR Adapter
1. From the following dialog, right-click on ControlNet and choose
New Module.
You see the Select Module dialog.
2. Right-click the + next to Communications to see the following
dialog.
3. Choose 1734-ACNR/A.
4. Click OK to see the New Module dialog.
5. Make the following entries.
