Rockwell Automation 1734-ACNR POINT I/O ControlNet Adapter User Manual User Manual
Page 50
Publication 1734-UM008B-EN-P - August 2005
4-20 Configure the Adapter
13. Specify a value for Media Redundancy on channel A, B or A and
B.
14. Click OK to see the Save As dialog.
15. Click Save to see the Save As dialog.
16. From the Save As dialog, enter a name and location for the file,
and click Save.
You see the Save Configuration dialog.
17. Click OK.
18. Notice the I/O OK is solid green.
