The following chart describes the parts that make up the catalog number for a
DataSite configured panel.
Radio
Code
Brand
Frequency
Comm.
NR
None
None
None
Space for radio included.
PS9E
Prosoft
900 MHz
Ethernet
PS9S
Prosoft
900 MHz
Serial
PS24E
Prosoft
2.4 GHz
Ethernet
PS24S
Prosoft
2.4 GHz
Serial
DL9E
Datalinc
900 MHz
Ethernet
DL9S
Datalinc
900 MHz
Serial
DL24E
Datalinc
2.4 GHz
Ethernet
DL24S
Datalinc
2.4 GHz
Serial
FW9E
FreeWave
900 MHz
Ethernet
FW9S
FreeWave
900 Mhz
Serial
FW24E
FreeWave
2.4 GHz
Ethernet
FW24S
FreeWave
2.4 GHz
Serial
Code Product Type
F
Enclosed with Flow Measurements (AGA)
R
Enclosed, RTU only
Code
Enclosed Options
Blank
No options
AL
Aluminum NEMA 4X enclosure, 60.96 x 50.8 x 25.4 cm (24 x 20 x 10 in.).
See note 6.
TB
RTU wired to control terminals. If not selected, no terminals provided.
HMI
IDEC display unit HG1X-222. See note 5.
24V
24V system voltage. This means 24V is available for field devices, but the
DataSite panel, radio and batteries remain at 12V DC. See note 8.
1-4
5
6
7-8
9
10
11
12-13
14
15-18
19
20-21
22
23
24-25
1748
-
F
DC
-
P
-
14
-
PS9E
-
10
Y
-
TB
Antenna Cable Length
Code Feet
Meters
NC
None
None
10
10
3.1
25
25
7.6
50
50
15.2
100
100
30.5
Bulletin Number
1748 DataSite Enclosure in
UL Type 4X polycarbonate
Code Antenna Brand
Y
Yagi
O
Omni
NA
No antenna
Code Analog Inputs
DC
0…10V DC
MA
4…20 mA
Code Mounting Type
W
Wall mounting kit
P
Pipe mounting kit
Notes:
1.
Unit is UL Class I Division 2 certified only when FreeWave 900 MHz radios are selected (options FW9E and FW9S).
2.
Solar panels are available from local RA authorized distributors.
Please see DataSite Configured Panel Application Techniques, publication 1748-AT001A-EN-P for proper sizing and selection.
Solar panels must meet UL Class I Division 2 if required.
3.
Standard system voltage is 12V DC.
4.
Radio surge suppressor included when a radio is specified.
5.
Human-machine interface (HMI) option includes:
2-line, 16-character or 4-line, 20 character backlit LCD HG1X-222 is 24V DC and supports RS232 or RS485 communications.
A 12V/24V voltage converter is included.
6.
Replaces NEMA 4X polycarbonate enclosure.
7.
DC-DC converter included for voltage conversion from 12…24 V DC.
8.
If a radio is not selected, antennas and cables cannot be selected.
Code Battery
14
14 Ah
28
28 Ah
56
56 Ah
Cable length between panel
and antenna must not be
longer than 30.5m (100 ft).
