Configuring Your Input Channels
Input Channel Configuration
03
02
01
00
Set these bits for Channel 0
07
06
05
04
Set these bits for Channel 1
Bit Settings
Input
Values
Data Format
% Underrange
%Overrange
Input Range
(2)
Module Update Rate
Hexadecimal
Decimal
(RTSI = 0)
(RTSI = 0)
IT = 1
0
0
0
0
Channel not configured
0
0
0
1
4–20mA
signed 2’s complement
4% Under; 4% Over
<0000–7878>
<0000–30840>
7.5ms
5.0ms
0
0
1
0
±10V
signed 2’s complement
2% Under, 2% Over
<831F–7CE1>
<–31969–31969>
2.5ms
2.5ms
0
0
1
1
±5V
signed 2’s complement
4% Under, 4% Over
<8618–79E8>
<–31208–31208>
2.5ms
2.5ms
0
1
0
0
0–20mA
signed 2’s complement %
0% Under, 4% Over
0–2710>
0–10000>
7.5ms
5.0ms
0
1
0
1
4-20mA
signed 2’s complement %
4% Under, 4% Over
<0–2710>
<0–10000>
7.5ms
5.0ms
0
1
1
0
0–10V
signed 2’s complement %
0% Under, 2% Over
0–2710>
0–10000>
5.0ms
5.0ms
0
1
1
1
±10V
signed 2’s complement %
2% Under, 2% Over
<–D8F0–2710>
<–10000–10000>
5.0ms
5.0ms
1
0
0
0
0–20mA
binary
0% Under, 4% Over
0000–F3CF>
0000–62415>
2.5ms
2.5ms
1
0
0
1
4–20mA
(1)
binary
4% Under, 4% Over
0000–F0F1>
0000–61681>
7.5ms
5.0ms
1
0
1
0
0–10V
binary
0% Under, 2% Over
0000–F9C2>
0000–63938>
2.5ms
2.5ms
1
0
1
1
0–5V
binary
0% Under, 4% Over
0000–F3CF>
0000–62415>
2.5ms
2.5ms
1
1
0
0
±20mA
offset binary, 8000H = 0mA
4% Under, 4% Over
<0618–F9E8>
<1560–63976>
2.5ms
2.5ms
1
1
0
1
4–20mA
offset binary, 8000H = 4mA
4% Under, 4% Over
<8000–F878>
<32768–63608>
7.5ms
5.0ms
1
1
1
0
±10V
offset binary, 8000H = 0V
2% Under, 2% Over
<031F–FCE1>
<799–64737>
2.5ms
2.5ms
1
1
1
1
±5V
offset binary, 8000H = 0V
4% Under, 4% Over
<0618–F9E8>
<1560–63976>
2.5ms
2.5ms
(1)
Underrange for 4-20mA occurs in the blind area below 0 (3.2mA).
(2)
< and > indicate the overrun beyond actual range (about 5%).
Table 5.13
Setting the Input Filter
Bits
Channel
03
02
01
00
Input Channel 0
07
06
05
04
Input Channel 1
A/D Conversion
Rate
Low Pass Filter
0
0
0
0
1200Hz
No low pass
0
0
0
1
1200Hz
100ms low pass
0
0
1
0
1200Hz
500ms low pass
0
0
1
1
1200Hz
1000ms low pass
0
1
0
0
600Hz
No low pass
0
1
0
1
600Hz
100ms low pass
0
1
1
0
600Hz
500ms low pass
