77 Publication 1746-UM009B-EN-P - September 2007
Appendix
A
Module Specifications
General Description The 1746-FIO4I and 1746-FIO4V fast analog I/O modules provide two
input and two output channels. Input channels are the same for both
types of modules: you select either current or voltage operation for
each channel. The 1746-FIO4I module contains two current-output
channels, while the 1746-FIO4V module contains two voltage-output
channels.
Specifications Specifications for the fast analog I/O modules include the following:
• general specifications.
• general input specifications.
• voltage input specifications.
• current-loop input specifications.
• current output specifications for the 1746-FIO4I.
• voltage output specifications for the 1746-FIO4V.
General Specifications
Catalog
1746- Input Channels
per Module Output Channels
per Module Backplane Current ID
Code
5 V 24 V
FIO4I Two differential,
voltage or current,
selectable per channel Two current outputs,
not individually
isolated 55 mA 150 mA 3224
FIO4V Same as FIO4I Two voltage outputs,
not individually
isolated 55 mA 120 mA 3218
Electrical Specifications - 1746-FIO4I, 1746-FIO4V
Attribute Value
Cable Shielded, Belden #8761 (recommended)
Wire Size
2.5 mm
2
(14 AWG) max
Terminal Block Removable
Installation Single slot in the 1746 I/O Rack
Calibration Every six months or as necessary
