Chapter
6
1512A-UM102B-EN-P – June 2013
Spare Parts
The following list of spare parts is valid for typical Bulletin 1512A and
1512AT units. Please contact your local Rockwell Automation office to ensure that
the following part numbers are available.
Part Number Description
Recommended
Stocking Quantity
80154-991-59 LV Control Panel  (Electrically Held) 1
80154-991-61 LV Control Panel  (Mechanical Latch) 1
1503VC-BMC5 IntelliVAC (Electrically Held and Mechanical Latch)   1
1503VC-BMC5-EM1 IntelliVAC Plus (Electrically Held and Mechanical Latch)  
80174-902-14-R Internal IntelliVAC fuse – 6.3A, 250 V (Littlefuse 21506.3)  1
Engineering Data  Power Fuses  3
Engineering Data  Primary Fuses (CPT/PT) 2
Engineering Data  LV Control Circuit Fuses 2
Engineering Data  Heater Elements (if used) 3
40266-515-03 20 Amp Isolation Switch Auxiliary Contact Cartridge (700 CPM) 2
80145-566-71 Isolation Switch Blade Assembly 800A 3
80158-357-51 Nyogel 759G Lubricant 3
RU-8216 Dow Corning 55 O-ring Lubricant 1
 The following is included with the LV Control Panel: CR1 relay, CR2 relay, rectifier, MOV assembly, test switch, test plug. Note: For
mechanical latch assemblies, an additional CR1 relay is substituted for the CR2 relay.
 Power fuses are R rated for motor loads or E rated for non-motor loads. Power fuses are sized to the motor or transformer load data
provided at the time the starter is ordered. Refer to dimensional drawings for specific fuse type and size. Bolt-on or clip-on fuses are
available for various load sizes. Contact Rockwell Automation for details.
 Consult spare parts list in service manuals that are provided following delivery of equipment.
 For starters with IntelliVAC control
 For starters with electro-mechanical control
 For starters with IntelliVAC Plus control
For 800A contactor spare parts, refer to Bulletin 1502
800A Medium Voltage Contactor User Manual,
- Publication 1502-UM051_-EN-P
