Installation – Arc Resistant (ArcShield) 3-3

1512A-UM102E-EN-P – June 2013

The Medium Voltage door is identified as MV in Figure 3.2.

I M P O R T A N T

Failure to follow the MV door opening procedure

could damage or jam the mechanical door

interlocks. This could result in the mechanical

interlocks not operating as intended and could
result in the door becoming jammed in the closed

position.

Note: On all ArcShield starters, the sticker shown in Figure 3.3 is
attached to each door for your reference.

1) Electrically open the contactor by pressing the STOP button on

the starter or at the remote control location.

2) Move the isolation switch handle to the OFF position.
3) Turn the black release handle counter clockwise 90 degrees.
4) Unbolt the door locking bolts for the upper right hand medium

voltage door.

5) The door is now released and will swing open.
6) The lower right hand MV door will now be able to be opened.

Unbolt the door locking bolts. Turn the release handle counter
clockwise. The door is now released and will swing open.

7) The lower left hand medium voltage door will now be able to be

opened. Unbolt the door locking bolts. Turn the release handle
counter clockwise. The door is now released and will swing open.

8) Reverse the procedure to close the door. Door lock bolts must be

adequately tightened. (Refer to page 1-3 for Torque Values).
