Chapter
4
1512A-UM102B-EN-P – June 2013
Common Installation
Bus Splicing Power Bus
A T T E N T I O N A T T E N T I O N
This procedure requires contact with medium
voltage components. To avoid shock hazards, lock
out incoming power before working on the
equipment. (See Power Lockout Procedure, page
5-3). Verify with a hot stick or appropriate voltage
measuring device that all circuits are voltage free.
Failure to do so may result in severe burns, injury
or death.
1) The power and ground bus splice kit can be found in a package
mounted to the front of the shipping skid.
I M P O R T A N T I M P O R T A N T
Verify that the structure series numbers on the splice
kit package match the structure series number found
on the cabinet nameplate (see page 1-2 for details
regarding the nameplate).
2) Refer to Access to the Power Bus, page 2-6 for Standard Enclosure
and Page 3-8 for ArcShield Enclosure.
3) For a 1200A power bus, assemble the splice bars as shown in Figure
2.20. Tighten the nuts to 48 ft·lb (65 N·m).
For a 2000A power bus, assemble the splice bars as shown in Figure
2.21. Tighten the nuts to 48 ft·lb (65 N·m).
I M P O R T A N T I M P O R T A N T
Attach the bus links to the cabinet on the left side
first - as viewed from the front of the unit.
I M P O R T A N T I M P O R T A N T
Always place the bus clamps on the rear side of each
main horizontal bus or splice bar, as viewed from the
front of the unit. (See Figure 4.1 or 4.2).
