Rockwell Automation Publication 440R-UM009B-EN-P - February 2014
61
Tag Definitions
Appendix D
0EH
Mismatch between current switch
settings and setting stored during
power-up.
Do one of the following:
• Change the switch settings to the correct values.
• Power cycle the safety relay.
• Reconfigure the safety relay.
technical support representative. For contact information, see:
0FH
EEPROM read/write failure
Do one of the following:
• Change the switch settings to the correct values.
• Power cycle the safety relay.
• Reconfigure the safety relay.
technical support representative. For contact information, see:
11H
Compare State Fault
13H
L52 Fault
16H
Cross Tran Fault
18H
Gate Open Fault: Indicates the Gate
inputs, S12, S22, unexpectedly opened.
19H
Over Speed 1
1EH
Terminal S12 hardware input fault
1FH
Terminal S22 hardware input fault
20H
Pulse test fault on main transistor
Do one of the following:
• Check wiring for shorts to 24V or other channels.
• Power cycle the safety relay.
• Reconfigure the safety relay.
• Validate the electrical installation and appropriate
measures to reduce noise and suppress surges are taken.
If the fault persists, contact your local Rockwell Automation
technical support representative. For contact information, see:
21H
Over voltage detected
Do one of the following:
• Validate the electrical installation and appropriate supply
voltage is provided.
• Power cycle the safety relay.
• Reconfigure the safety relay.
If the fault persists, contact your local Rockwell Automation
technical support representative. For contact information, see:
22H
S54_S54 Autostart fault
28H-39H
Rom Fault
Do one of the following:
• Power cycle the safety relay.
• Reconfigure the safety relay.
• Validate the electrical installation and appropriate
measures to reduce noise and suppress surges are taken.
If the fault persists, contact your local Rockwell Automation
technical support representative. For contact information, see:
Table 12 - GSR GLP NonRecoverableFault_A and NonRecoverableFault_B Fault Codes
Fault
Code
Description
Corrective Action
