54 Rockwell Automation Publication 440R-UM009B-EN-P - February 2014
Appendix D Tag Definitions
Table 8 - GSR EM Module Input Tags
Name Data Type Definition
Slotx_GSR_EM_SingleWireSafetyIn BOOL Single Wire Safety Input Status – Indicates whether the
Single Wire Safety input (L12) is On or Off.
0 = The Single Wire Safety input signal is Off.
1 = The Single Wire Safety input signal is On.
Slotx_GSR_EM_SafetyOutput BOOL Safety Output Status – Indicates whether the safety
output channels are On or Off.
0 = The safety output channels are Off.
1 = The safety input channels are On.
Slotx_GSR_EM_RecoverableFault BOOL Recoverable Fault Status – Toggles On (1) for one scan
when the safety relay has detected unexpected operation of
a monitored safety device. See RecoverableFaultA for
details.
0 = No fault
1 = Fault
Slotx_GSR_EM_NonRecoverableFault BOOL Non-Recoverable Fault Status – Toggles On (1) for one
scan when the safety relay has detected unexpected
internal operation or failed a pulse check. See
NonRecoverableFault_A and NonRecoverableFault_B for
details.
0 = No fault
1 = Fault
Slotx_GSR_EM_NonRecoverableFault_A SINT Non-Recoverable Fault Processor A – Indicates a
non­recoverable fault has been recorded by Safety
Processor A. See
Table 10 on page 56 for a list of non-
recoverable fault codes.
Slotx_GSR_EM_NonRecoverableFault_B SINT Non-Recoverable Fault Processor B – Indicates a
non­recoverable fault has been recorded by Safety
Processor B. See
Table 10 on page 56 for a list of non-
recoverable fault codes.
