Appendix
D
Tag Definitions
Table 6 - GSR DI(S) Module Input Tags
Name
Data Type
Definition
Slotx_GSR_DIS_IN01
BOOL
IN01 Status - Indicates whether input circuit 1 is On or Off.
0 = The input channel is Off.
1 = The input channel is On.
Slotx_GSR_DIS_IN02
BOOL
IN02 Status - Indicates whether input circuit 2 is On or Off.
0 = The input channel is Off.
1 = The input channel is On.
Slotx_GSR_DIS_SingleWireSafetyIn
BOOL
Single Wire Safety Input Status - Indicates whether the
Single Wire Safety input (L12) is On or Off.
0 = The Single Wire Safety input signal is Off.
1 = The Single Wire Safety input signal is On.
Slotx_GSR_DIS_ResetRequired
BOOL
Reset Required Indication - This indication turns On (1)
when all monitored input conditions are On and the safety
relay Output is Off (0).
Slotx_GSR_DIS_CrossLoopOK
BOOL
Cross Loop OK - Indicates whether the safety relay is
detecting a cross loop fault on one of the input circuits.
0 = Cross loop fault
1 = No fault
Slotx_GSR_DIS_SafetyOutput
BOOL
Safety Output Status – Indicates whether the safety
output channels are On or Off.
0 = The safety output channels are Off.
1 = The safety input channels are On.
Slotx_GSR_DIS_RecoverableFault
BOOL
Recoverable Fault Status – Toggles On (1) for one scan
when the safety relay has detected unexpected operation of
a monitored safety device. See S12 OpenWire, S22
OpenWire, S32 OpenWire, S42 OpenWire, Cross Loop Fault,
Invalid Switch Setting, and Reset Held On (
) for
details.
0 = No fault
1 = Fault
Slotx_GSR_DIS_NonRecoverableFault
BOOL
Non-Recoverable Fault Status – Toggles On (1) for one
scan when the safety relay has detected unexpected
internal operation or failed a pulse check. See
NonRecoverableFault_A and NonRecoverableFault_B (
) for details.
0 = No fault
1 = Fault
Slotx_GSR_DIS_S12
BOOL
S12 Status – Indicates whether terminal S12 of circuit IN01
is On or Off.
0 = The terminal is Off.
1 = The terminal is On.
Slotx_GSR_DIS_S22
BOOL
S22 Status – Indicates whether terminal S22 of circuit IN02
is On or Off.
0 = The terminal is Off.
1 = The terminal is On.
Slotx_GSR_DIS_S32
BOOL
S32 Status – Indicates whether terminal S32 of circuit IN02
is On or Off.
0 = The terminal is Off.
1 = The terminal is On.
